D32CPM1PH Nidec | 1.5 hp 3600 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor

SKU:
D32CPM1PH
Availability:
Subject to availability
Weight:
32.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $666.00
Now: $594.90
Adding to cart… The item has been added
  • 1.5 hp 3600 RPM, 13.3/6.7 amps 115/230 Volts 60hz. Single Phase Motor
  • NEMA 56H Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • ODP; Service Factor: 1.15, Overload protection = None
  • Reversible, Rigid Base Mount, Ball Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Continuous Duty.  Wiring diagram on motor name plate. ODP = Open Drip Proof
