Model 9431A Century 1/6 hp 1075 RPM 3-Speed 277V 5.6" Diameter Furnace Motor Century # 9431A

Model 9431A Century 1/6 hp 1075 RPM 3-Speed 277V 5.6" Diameter Furnace Motor

This Model 9431A Century furnace motor is a direct drive blower motor designed for residential and commercial HVAC applications. It replaces Century #9431A and is suitable for furnaces requiring a 1/6 horsepower, 3-speed motor operating at 277 volts.

Key Specifications

• Horsepower: 1/6 hp
• RPM: 1075
• Voltage: 277 V
• Amperage: 0.78 A
• Frame / Diameter: 5.6" Diameter
• Shaft Dimensions: 1/2" diameter x 5.5" length
• Rotation: Reversible
• Bearings: Sleeve Bearings

Product Features & Fitment

The motor features a torsion flex mount and is designed for all-angle mounting with sleeve bearings. It includes 24" leads for easy wiring and requires a 5 MFD 370V capacitor (Century Part #5DV) for proper operation. The motor is thermally protected, UL recognized, CSA certified, and open ventilated with air-over cooling to ensure reliable performance in furnace blower applications.

Warranty

1 Year Manufacturer Warranty
