3700-E Nidec | 1/6 hp 900 RPM 48 Frame 115V Open Drip Nidec Electric Motor

3700-E Nidec | 1/6 hp 900 RPM 48 Frame 115V Open Drip Nidec Electric Motor

SKU:
3700-E
Availability:
Subject to availability
Weight:
23.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $552.00
Now: $493.00
Adding to cart… The item has been added
  • 1/6 hp 900 RPM, 4.5 amps 115 Volts 60hz. Single Phase Motor
  • NEMA 48 Frame Keyed Shaft 1/2" Diameter x 1 7/8"
  • Service Factor: 1.35, Overload protection = Auto
  • Reversible, Resilient Base Mount, Sleeve Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Wiring diagram on motor name plate. ODP = Open Drip Proof

C055TBK4336012B

!
