3700-E Nidec | 1/6 hp 900 RPM 48 Frame 115V Open Drip Nidec Electric Motor
3700-E Nidec | 1/6 hp 900 RPM 48 Frame 115V Open Drip Nidec Electric Motor
3700-E Nidec | 1/6 hp 900 RPM 48 Frame 115V Open Drip Nidec Electric Motor
3700-E Nidec | 1/6 hp 900 RPM 48 Frame 115V Open Drip Nidec Electric Motor

Nidec

3700-E Nidec | 1/6 hp 900 RPM 48 Frame 115V Open Drip Nidec Electric Motor

(No reviews) Write a Review
$634.80
$566.95
SKU 3700-E
UPC 6.63E+11
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115V
Horsepower 1/6 HP
RPM 900
Phase Single Phase
Frame 48
Enclosure ODP
Hertz 60 Hz
Amperage 4.5 Amps
Bearings Sleeve Bearings
Service Factor 1.35
Insulation Class Class B
Adding to cart… The item has been added
Description
  • 1/6 hp 900 RPM, 4.5 amps 115 Volts 60hz. Single Phase Motor
  • NEMA 48 Frame Keyed Shaft 1/2" Diameter x 1 7/8"
  • Service Factor: 1.35, Overload protection = Auto
  • Reversible, Resilient Base Mount, Sleeve Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Wiring diagram on motor name plate. ODP = Open Drip Proof

C055TBK4336012B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115V
Horsepower 1/6 HP
RPM 900
Phase Single Phase
Frame 48
Enclosure ODP
Hertz 60 Hz
Amperage 4.5 Amps
Bearings Sleeve Bearings
Service Factor 1.35
Insulation Class Class B
!
