GT1201 Marathon 1 hp 1800 RPM 3-Phase 143TC Frame TEFC (rigid base) 230/460V Marathon Motor

SKU:
GT1201
Weight:
42.00 LBS
Shipping:
Free Shipping
ON SALE:
DISCOUNTED PRICES AND FREE GROUND SHIPPING
Was: $402.30
Now: $369.10
Adding to cart… The item has been added
  • 1 hp 1800 RPM, 3.3/1.7 amps 230/460 Volts 60 Hz 3-Phase
  • NEMA 143TC frame, C-face, Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor with a C-face mount. Shaft has keyway. Motor has 4 threaded bolt holes on face for mounting a pump or gear head to the motor. Bolt holes are 5 7/8" on center measured across the shaft. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. 143TTFR6032
