- 1 hp 1800 RPM, 3.0/1.5 amps 230/460 Volts 60 Hz 3-Phase, Encoder attached
- NEMA 143TC Cast Iron frame, C-face, Keyed Shaft 7/8" Diameter x 2 1/4"
- Service Factor: 1.0, Overload protection = None
- Rigid Base, Reversible, Ball Bearings, Class F Insulation
- 1 Year Manufacture Warranty
Inverter (Vector) duty Explosion Proof, three phase electric motor with a C-face mount. 2000:1 constant torque. Shaft has keyway. Motor has 4 threaded bolt holes on face for mounting a pump or gear head to the motor. Bolt holes are 5 7/8" on center measured across the shaft. Wiring diagram on motor name plate. TENV = Totally Enclosed Non-Ventilated.
Model #:143THEN8034CB, Part #:143THEN8034
