This Leeson 1 hp, 1800 RPM permanent magnet DC motor is designed for low voltage applications such as battery or solar-powered systems. It serves as an exact replacement for the Dayton 6ML07 motor and is ideal for heavy load operations requiring high starting torque and dynamic braking capabilities.

Key Specifications

• Horsepower: 1 hp
• RPM: 1800
• Voltage: 24 Volts DC
• Amperage: 39.0 Amps
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: NEMA 56C Frame
• Bearings: Sealed ball bearings

Product Features & Fitment

The motor features a 56C face with a removable bolt-on base for flexible mounting options. It offers linear speed/torque characteristics across the entire speed range and supports reversible operation via a simple 2-lead connection. Compatible with Leeson speed control model 175291, this motor is well-suited for applications requiring reliable dynamic braking and robust performance.

Cross Reference

• Dayton 6ML07 (The Dayton is actually made by Leeson Electric). Can use with Leeson speed control 175291
• C4D17FK9E, 108053.00

Warranty

1 Year Manufacturer Warranty
