FD1CM2PZY Nidec | 1 hp 1800 RPM 56Y Frame TEFC 115/208-230V Nidec Electric Auger Drive Moto

SKU:: FD1CM2PZY
UPC:
Weight:: 38.00 LBS
Width:: 23.00 (in)
Height:: 15.00 (in)
Depth:: 12.00 (in)
Shipping:: Free Shipping
ON SALE:: LIMITED TIME DISCOUNT
Voltage:: 115/208-230V
Horsepower:: 1 HP
RPM:: 1800
Frame:: 56Y Frame
Enclosure:: TEFC
Hertz:: 60 Hz
Amperage:: 12.8/6.4 Amps
Bearings:: Ball Bearings
Insulation Class:: Class F
Rotation:: Reversible
Mounting:: Rigid Base
Duty:: continuous duty

Current Stock:

Was: $335.80

Now: $259.95

Quantity:

Adding to cart… The item has been added

Description
Literature
Compliance & Restrictions

FD1CM2PZY Nidec | 1 hp 1800 RPM 56Y Frame TEFC 115/208-230V Nidec Electric Auger Drive Motor

This Nidec Electric Auger Drive Motor is designed for direct drive applications in poultry and swine feeding systems. It serves as a reliable replacement motor featuring a robust design suitable for continuous duty in agricultural environments.

Key Specifications

Horsepower: 3/4 hp
RPM: 1800
Voltage: 115/208-230V
Amperage: 12.8/6.4 amps
Enclosure: TEFC (Totally Enclosed Fan Cooled)
Frame / Diameter: 56Y Frame
Shaft Dimensions: 5/8" Diameter x 2.1" Keyway with flat
Rotation: Reversible
Bearings: Ball Bearings

Product Features & Fitment

The motor features a rigid base with a C-face mount for secure installation. It includes manual overload protection and Class F insulation, designed to operate continuously at 40°C ambient temperature. This motor is engineered for durability and ease of integration into existing feeding system setups.
