2B110-SK Pulley | 11.35" OD Double Groove "A/B" Pulley / Sheave (bushing not included)
2B110-SK Pulley | 11.35" OD Double Groove "A/B" Pulley / Sheave (bushing not included)
2B110-SK Pulley | 11.35" OD Double Groove "A/B" Pulley / Sheave (bushing not included)
2B110-SK Pulley | 11.35" OD Double Groove "A/B" Pulley / Sheave (bushing not included)

Leeson/AMEC

2B110-SK Pulley | 11.35" OD Double Groove "A/B" Pulley / Sheave (bushing not included)

(No reviews) Write a Review
$95.00
$89.95
SKU 2B110-SK
Shipping Free Shipping
Pulley Type Bushing Type
Belt Section A/B
Grooves 2
Bore Size Bushing Required
Pitch Diameter 8" - 12"
Material Cast Iron
Adding to cart… The item has been added
Description

2B110-SK Pulley | 11.35" OD Double Groove "A/B" Pulley / Sheave

The 2B110-SK is a double groove cast iron pulley designed for use with A, 4L, and B, 5L V-belts. It is ideal for industrial motor and HVAC applications requiring reliable power transmission with QTL quick detachable taper bushings.

Key Specifications

  • Frame / Diameter: 11.35" Outside Diameter
  • Pitch Diameter A: 10.60"
  • Pitch Diameter B: 11.00"

Product Features & Fitment

This pulley requires an "SK" style bushing, which is not included. It is compatible with QTL quick detachable taper bushings for easy installation and removal. Depending on the diameter, the pulley may be solid or spoked to reduce weight. Please consult Electric Motor Warehouse for assistance in selecting the correct bushing. Note that the product image is a general representation and actual pulley diameter may vary based on size.

Warranty

Warranty Information
Specifications
Pulley Type Bushing Type
Belt Section A/B
Grooves 2
Bore Size Bushing Required
Pitch Diameter 8" - 12"
Material Cast Iron
!
