Motor Discontinued
- 10 hp 1800 RPM, 27.0/13.5 amps 230/460 Volts 60 Hz 3-Phase. Encoder Ready
- NEMA 215TC Aluminum frame, C-face, Keyed Shaft 1 3/8" Diameter x 3 3/8"
- Service Factor: 1.0, Overload protection = None
- Rigid Base, Reversible, Ball Bearings, Class F Insulation
- 1 Year Manufacture Warranty
Inverter (Vector) duty three phase electric motor with a C-face mount. 1000:1 constant torque. Shaft has keyway. Motor has 4 threaded bolt holes on face for mounting a pump or gear head to the motor. Bolt holes are 5 7/8" on center measured across the shaft. Wiring diagram on motor name plate. TENV = Totally Enclosed Non-Ventilated. 215THTL7726
