Leeson/Marathon
116919.00 Leeson Extreme Duck 3/4 hp 1200 RPM 115/208-230V 3-Phase 56H Frame TENV (base) Motor
(No reviews)
Write a Review
Write a Review
Leeson/Marathon
116919.00 Leeson Extreme Duck 3/4 hp 1200 RPM 115/208-230V 3-Phase 56H Frame TENV (base) Motor
$1,439.33
SKU
116919
UPC
6.92E+11
Shipping
Free Shipping
Voltage
115/208/230V
Horsepower
3/4 HP
RPM
1200
Phase
Three Phase
Frame
56H
Enclosure
TENV
Hertz
60 Hz
Amperage
4.2 Amps
Bearings
Ball Bearings
Service Factor
1.15
Insulation Class
Class F
Mounting
Rigid Base
- 3/4 hp 1200 RPM, 8.4/4.4-4.2 amps 115/208-230 Volts 60 Hz. Three Phase
- NEMA 56H frame, Stainless Steel Keyed Shaft 5/8" Diameter x 1 7/8"
- Service Factor: 1.15, Overload protection = None
- Rigid Base, Reversible, Ball Bearings, Class F Insulation
- 1 Year Manufacture Warranty,
Stainless Steel wash-down motors are use in applications involving challenging caustic environments. This is a three phase electric motor. Shaft has keyway. Wiring diagram on motor name plate. TENV = Totally Enclosed Non-Ventilated. 116919.00
| Voltage | 115/208/230V |
|---|---|
| Horsepower | 3/4 HP |
| RPM | 1200 |
| Phase | Three Phase |
| Frame | 56H |
| Enclosure | TENV |
| Hertz | 60 Hz |
| Amperage | 4.2 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.15 |
| Insulation Class | Class F |
| Mounting | Rigid Base |
