4C130-E Pulley | 13.40" OD Four Groove Pulley / Sheave for "C" Style V-Belt (bushing not included)
4C130-E Pulley | 13.40" OD Four Groove Pulley / Sheave for "C" Style V-Belt (bushing not included)
4C130-E Pulley | 13.40" OD Four Groove Pulley / Sheave for "C" Style V-Belt (bushing not included)
4C130-E Pulley | 13.40" OD Four Groove Pulley / Sheave for "C" Style V-Belt (bushing not included)

Leeson/AMEC

4C130-E Pulley | 13.40" OD Four Groove Pulley / Sheave for "C" Style V-Belt (bushing not included)

(No reviews) Write a Review
$306.35
$275.71
SKU 4C130-E
UPC 6.63E+11
Shipping Free Shipping
Pulley Type Bushing Type
Belt Section C
Grooves 4
Bore Size Bushing Required
Pitch Diameter 12"+
Material Cast Iron
Adding to cart… The item has been added
Description

4C130-E Pulley | 13.40" OD Four Groove Pulley / Sheave for "C" Style V-Belt

The 4C130-E is a four-groove cast iron pulley designed for use with "C" style V-belts. It is compatible with QTL Quick Detachable Taper Lock (QDTL) bushings and is ideal for industrial motor and HVAC applications requiring reliable power transmission.

Key Specifications

  • Frame / Diameter: 13.40" OD
  • Grooves: Four
  • Bushing Type: Requires "E" style QTL Quick Detachable Taper Bushing

Product Features & Fitment

This pulley requires an "E" style QTL bushing, which is not included and must be selected separately. The pulley may be solid or spoked depending on the diameter to optimize weight. Please consult Electric Motor Warehouse for assistance in selecting the correct bushing. Note that the product image is a general representation; actual diameter and design may vary based on size.

Warranty

Warranty Information
Specifications
Pulley Type Bushing Type
Belt Section C
Grooves 4
Bore Size Bushing Required
Pitch Diameter 12"+
Material Cast Iron
!
