BMU2P2DCR Nidec | 2 hp 1800 RPM 145TC Frame 208-230/460V TEFC Nidec C-Face Electric Brake Motor
BMU2P2DCR Nidec | 2 hp 1800 RPM 145TC Frame 208-230/460V TEFC Nidec C-Face Electric Brake Motor
BMU2P2DCR Nidec | 2 hp 1800 RPM 145TC Frame 208-230/460V TEFC Nidec C-Face Electric Brake Motor
BMU2P2DCR Nidec | 2 hp 1800 RPM 145TC Frame 208-230/460V TEFC Nidec C-Face Electric Brake Motor

Nidec

BMU2P2DCR Nidec | 2 hp 1800 RPM 145TC Frame 208-230/460V TEFC Nidec C-Face Electric Brake Motor

(No reviews) Write a Review
$1,991.80
$1,778.82
SKU BMU2P2DCR
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 2 HP
RPM 1800
Phase Three Phase
Frame 145TC
Enclosure TEFC
Amperage 5.7/2.8 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting C-Face
Adding to cart… The item has been added
Description
  • 2 hp 1800 RPM, 5.7/2.8 amps 208-230/460 Volts 3 phase Motor
  • NEMA 145TC Frame Keyed shaft 7/8" Diameter x 2 1/4"
  • Face Mount-No Base
  • 10 Foot Pounds
  • Service Factor: 1.25, Overload protection = None
  • Reversible, Ball Bearings, Class F Insulation
  • TEFC = Totally Enclosed Fan-Cooled
  • 40C Ambient Temp.
  • 1 Year Manufacture Warranty

Unimount Brake Motor

Model FR32

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 2 HP
RPM 1800
Phase Three Phase
Frame 145TC
Enclosure TEFC
Amperage 5.7/2.8 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting C-Face
!
