D2P1G Nidec | 2 hp 3600 RPM 145T Frame 575V Open Drip Nidec Electric Motor
D2P1G Nidec | 2 hp 3600 RPM 145T Frame 575V Open Drip Nidec Electric Motor
D2P1G Nidec | 2 hp 3600 RPM 145T Frame 575V Open Drip Nidec Electric Motor
D2P1G Nidec | 2 hp 3600 RPM 145T Frame 575V Open Drip Nidec Electric Motor
D2P1G Nidec | 2 hp 3600 RPM 145T Frame 575V Open Drip Nidec Electric Motor
D2P1G Nidec | 2 hp 3600 RPM 145T Frame 575V Open Drip Nidec Electric Motor

Nidec

D2P1G Nidec | 2 hp 3600 RPM 145T Frame 575V Open Drip Nidec Electric Motor

(No reviews) Write a Review
$483.00
$430.91
SKU D2P1G
UPC 6.63E+11
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 2 HP
RPM 3600
Phase Three Phase
Frame 145T
Enclosure ODP
Amperage 2.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 2 hp 3600 RPM, 2.0 amps 575 Volts Three Phase Motor
  • NEMA 145T frame, Keyed Shaft 7/8" Diameter x 2 1/4"
  • ODP; Service Factor: 1.15, Overload protection = None
  • Reversible, Rigid Base Mount, Ball Bearings, Class F Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor. Continuous Duty.  Premium efficient. 40C Ambient Temp. Wiring diagram on motor name plate. ODP = Open Drip Proof

Model FE32, Dayton 6YT27

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 2 HP
RPM 3600
Phase Three Phase
Frame 145T
Enclosure ODP
Amperage 2.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Continuous Duty
!
