119482.00 Leeson | 2 hp 3600 RPM 56HC Frame TEFC 208-230/460V Wash Down Duty

119482.00 Leeson | 2 hp 3600 RPM 56HC Frame TEFC Wash Down Duty Motor

This Leeson 2 hp, 3600 RPM three-phase motor is designed for wash down duty applications, providing reliable performance in harsh environments. It replaces models 113592.00 and Marathon N609A (056T34W99022), making it a suitable upgrade or replacement for compatible equipment.

Key Specifications

• Horsepower: 2 hp
• RPM: 3600
• Voltage: 208-230/460 V
• Amperage: 4.8/2.4 A
• Enclosure: TEFC (Totally Enclosed Fan Cooled)
• Frame / Diameter: NEMA 56HC
• Shaft Dimensions: 5/8" Diameter x 1 7/8" Length

Product Features & Fitment

This Leeson Washguard motor features a rigid base for secure mounting and a keyed shaft for reliable coupling. It includes stainless steel components such as the shaft, conduit box cover, nameplate, and fan guard to resist corrosion. The motor is equipped with special gaskets, slingers, seals, and four endshield drains to enhance moisture resistance, supported by the IRIS insulation system and Class F insulation materials.

Cross Reference

• 113592.00
• Replaces Marathon N609A, 056T34W99022

Warranty

1 Year Manufacturer Warranty
