GT3428A Marathon 25 hp 1800 RPM 284JP Frame TEFC 230/460V Marathon Close Couple Motor

GT3428A Marathon 25 hp 1800 RPM 284JP Frame TEFC 230/460V Marathon Close Couple Motor

SKU:
GT3428A
Weight:
500.00 LBS
Width:
40.00 (in)
Height:
30.00 (in)
Depth:
24.00 (in)
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
230/460V
Horsepower:
25 HP
RPM:
1800
Phase:
Three Phase
Frame:
284JP
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
61.0/30.5 Amps
Bearings:
Ball Bearings
Insulation Class:
Class F
Mounting:
Rigid Base
Duty:
Continuous duty
Was: $3,820.88
Now: $2,454.10
Adding to cart… The item has been added
  • 25 hp 1800 RPM 284JPM Frame, 61.0/30.5 amps 230/460V 60hz. Three Phase Motor
  • Close Coupled Pump Motor - Rigid Base
  • Totally Enclosed Fan Cooled - Service Factor = 1.15
  • Class F Insulation; No Overload Protection
  • Continuous duty; Ball Bearings
  • One Year Manufacture Warranty

Close Coupled Pump Motor. Designed for continuous duty service on close Coupled pumps. Motor has rigid base. Wiring diagram on motor name plate.

284TTFCD6037 Replaces Leeson B199121.00, B199121, 199121.00, 199121; Dayton 29FH50

!
