3097 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Motor
3097 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Motor
3097 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Motor
3097 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Motor
3097 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Motor
3097 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Motor

Nidec

3097 Nidec | 3/4 hp 1075 RPM 1-Speed 208-230V; 5.6" Condenser Motor

(No reviews) Write a Review
$196.65
$175.94
SKU 3097
UPC 6.63E+11
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 3/4 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 4.7 Amps
Bearings Sleeve Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Reversible
Mounting Stud
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 3/4 hp 1075 RPM 1-Speed 208-230V 4.7 amps
  • Shaft 1/2" x 5"
  • Rotation: Reversible
  • 5.6" Diameter
  • Motor case length 6.1"
  • Sleeve bearings
  • Stud mount
  • Shaft up or horizontal mounting
  • Includes 7.5 MFD 2-prong capacitor
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Open Drip-Proof Air Over Enclosure; Class B Insulation; 60C Ambient Temperature; 30" Leads, K055SPH9906012B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 3/4 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 4.7 Amps
Bearings Sleeve Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Reversible
Mounting Stud
Duty Continuous Duty
!
