098069.00 Leeson | 3/4 hp 1800 RPM 180 Volts DC 56C Frame TEFC

098069.00 Leeson | 3/4 hp 1800 RPM 180 Volts DC 56C Frame TEFC

This Leeson 3/4 horsepower permanent magnet DC motor operates at 1800 RPM and 180 Volts DC. Designed for applications requiring adjustable speed and constant torque, it is compatible with SCR controllers and suitable for dynamic braking and reversible rotation needs.

Key Specifications

• Horsepower: 3/4 hp
• RPM: 1800
• Voltage: 180 Volts DC
• Amperage: 3.8 amps
• Enclosure: TEFC (Totally Enclosed Fan Cooled)
• Frame / Diameter: NEMA 56C Frame
• Shaft Dimensions: 5/8" Diameter Keyed shaft
• Rotation: Reversible

Product Features & Fitment

The motor features a 56C face with a removable bolt-on base. When removing the base, reinstall bolts with washers to compensate for base thickness. It is UL and CSA listed and meets NEMA MG1 standards with Class F insulation. Compatible with Leeson speed controls 174307 and 174308 for enhanced speed regulation. The motor’s simple 2-lead connection facilitates reversible rotation.

Warranty

1 Year Manufacturer Warranty
