D34CPM2PH Nidec | 3/4 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor

D34CPM2PH Nidec | 3/4 hp 1800 RPM 56H Frame 115/230V Open Drip Nidec Electric Motor

SKU:
D34CPM2PH
Availability:
Subject to availability
Weight:
29.00 LBS
Width:
10.00 (in)
Height:
10.00 (in)
Depth:
14.00 (in)
Shipping:
Free Shipping
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
115/230V
Horsepower:
3/4 HP
RPM:
1800
Phase:
Single Phase
Frame:
56H Frame
Enclosure:
ODP
Hertz:
60 Hz
Amperage:
7.0/3.5 Amps
Bearings:
Ball Bearings
Service Factor:
1.25
Insulation Class:
Class B
Mounting:
Rigid Base
Duty:
Continuous Duty
Was: $719.90
Now: $642.85
Adding to cart… The item has been added
  • 3/4 hp 1800 RPM, 7.0/3.5 amps 115/230 Volts 60hz. Single Phase Motor
  • NEMA 56H Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • ODP; Service Factor: 1.25, Overload protection = Manual
  • Reversible, Rigid Base Mount, Ball Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Continuous Duty.  Wiring diagram on motor name plate. ODP = Open Drip Proof
