Motor Discontinued
- 3 hp 1800 RPM, 8.4/4.2 amps 230/460 Volts 60 Hz. 3-Phase
- NEMA 182TC frame, C-face, Keyed Shaft 1 1/8" Diameter x 2 3/4"
- Service Factor: 1.0, Overload protection = None
- Rigid Base, Reversible, Ball Bearings, Class H Insulation
- 1 Year Manufacture Warranty
Inverter (Vector) duty three phase electric motor with a C-face mount. 1000:1 constant torque. Shaft has keyway. Motor has 4 threaded bolt holes on face for mounting a pump or gear head to the motor. Bolt holes are 5 7/8" on center measured across the shaft. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. 182THFW7729
