3187C Nidec 1 hp 1800 RPM 115/230V 5.6" Dia. (Base) 1-Speed ODP Belt Drive Motor
3187C Nidec 1 hp 1800 RPM 115/230V 5.6" Dia. (Base) 1-Speed ODP Belt Drive Motor
3187C Nidec 1 hp 1800 RPM 115/230V 5.6" Dia. (Base) 1-Speed ODP Belt Drive Motor
3187C Nidec 1 hp 1800 RPM 115/230V 5.6" Dia. (Base) 1-Speed ODP Belt Drive Motor

Nidec

3187C Nidec 1 hp 1800 RPM 115/230V 5.6" Dia. (Base) 1-Speed ODP Belt Drive Motor

(No reviews) Write a Review
$579.60
$517.73
SKU 3187C
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 1 HP
RPM 1800
Enclosure ODP
Hertz 60 Hz
Amperage 14.0/7.0 Amps
Bearings Sleeve Bearings
Speeds 1-Speed
Insulation Class Class B
Adding to cart… The item has been added
Description
  • 1 hp 1800 RPM (1 speed), 14.0/7.0 amps 115/230V Volts 60 Hz Capacitor Start Motor
  • 5.6" Dia. Frame, Rolled Steel, Flat Shaft 5/8" Diameter x 1 7/8"
  • Service Factor = 1.25, Overload Protection: Auto
  • Resilient Base Mount, Sleeve Bearings, Class B Insulation, Rev
  • 1 Year Manufacture Warranty

Belt Drive Fan Motor for central HVAC systems. Wiring diagram on motor name plate. ODP = Open Drip-Proof, C063SEY3817972B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 1 HP
RPM 1800
Enclosure ODP
Hertz 60 Hz
Amperage 14.0/7.0 Amps
Bearings Sleeve Bearings
Speeds 1-Speed
Insulation Class Class B
!
