3261 Nidec 3/4 hp 1725 RPM 115/230V Bell & Gossett (111047) Circulator Pump Replacement Motor

3261 Nidec • 3/4 hp 1725 RPM 115/230V Bell & Gossett (111047) Circulator Pump Replacement Motor

This 3/4 horsepower circulator pump motor is designed as a direct replacement for Bell & Gossett model 111047 and compatible with several Armstrong and Rotom models. It is ideal for hot water circulation applications requiring reliable, capacitor start operation.

Key Specifications

• Horsepower: 3/4 hp
• RPM: 1725
• Voltage: 115/208-230 V
• Amperage: 8.2/4.7-4.2 A
• Frame / Diameter: NEMA 48YZ
• Bearings: Sleeve all-angle bearings

Product Features & Fitment

The motor features a resilient bracket mount and a special hot water circulator shaft designed for durability in hydronic systems. It includes an automatic overload protection and Class B insulation for enhanced reliability. Suggested replacement references include Rotom CP-R1462, Armstrong 811757-002, 116641-062, 811757-033, and Bell & Gossett 111047, 169230, as well as part numbers M80077, M80081, M80082, and MAGOOD-7606B.

Cross Reference

• Rotom CP-R1462
• Armstrong 811757-002, 116641-062; 811757-033
• Bell & Gossett 111047, 169230
• Replaces: M80077, M80081, M80082, MAGOOD-7606B

Warranty

1 Year Manufacturer Warranty
