3420610-1U Waterway | 1.5 hp 2-Speed 115V Waterway Spa Pump 48 Frame Aqua-Flo model EX2, XP2, XP2e

SKU:: 3420610-1U
UPC:
Weight:: 32.00 LBS
Width:: 24.00 (in)
Height:: 12.00 (in)
Depth:: 12.00 (in)
Shipping:: Free Shipping
ON SALE:: DISCOUNTED & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage:: 115V
Horsepower:: 1.5 HP
RPM:: 3450
Frame:: 48
Hertz:: 60 Hz
Amperage:: 13.3/4.1 Amps
Speeds:: 2-Speed

Current Stock:

Was: $451.38

Now: $419.74

Quantity:

Adding to cart… The item has been added

Description
Literature
Compliance & Restrictions

3420610-1U Waterway 1.5 hp 2-Speed 115V Spa Pump (Aqua-Flo EX2, XP2, XP2e Replacement)

This Waterway 3420610-1U is a 1.5 hp, 2-speed spa pump designed as a direct replacement for Aqua-Flo XP2 and XP2e 48 frame pumps. It is ideal for spa and hot tub applications requiring reliable performance and compatibility with existing Aqua-Flo installations.

Key Specifications

Horsepower: 1.5 hp
RPM: 3450 / 1725
Voltage: 115V 60Hz
Amperage: 13.3 / 4.1 amps
Frame / Diameter: 48 Frame, 3 inch inlet/outlet diameter

Product Features & Fitment

The pump features a side discharge wet end that can be rotated for flexible installation options. It includes two 400-5570 unions compatible with 2" PVC piping to facilitate easy plumbing connections. This model matches the physical dimensions of the Aqua-Flo XP2 and XP2e pumps, ensuring straightforward replacement without modification.
