4936 Nidec 1 hp 1140 RPM 575V 56YZ Frame (Rigid Base) 1-Speed TEAO 3-Phase Commercial Motor

4936 Nidec 1 hp 1140 RPM 575V 56YZ Frame (Rigid Base) 1-Speed TEAO 3-Phase Commercial Motor

SKU:
4936
Weight:
23.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $516.00
Now: $461.00
Adding to cart… The item has been added
  • 1 hp 1140 RPM, 1.5 amps 575V Volts 60 Hz 3-Phase Motor
  • NEMA 56YZ Frame, Rolled Steel, Flat Shaft 5/8" Diameter x 3" long
  • Service Factor = 1.0, Overload Protection: Auto
  • Base Mount, Ball Bearings, Class B Insulation, Rev
  • 1 Year Manufacture Warranty

Commercial Condenser Fan Motor. Wiring diagram on motor name plate. TEAO = Totally-Enclosed Air-Over, P063GEE4942015B

!
