6078 Nidec 1/2 hp 1800 RPM 120/240V ODP 1-Phase Carbonator Pump Motor Replacement

6078 Nidec 1/2 hp 1800 RPM 120/240V ODP 1-Phase Carbonator Pump Motor Replacement

This Nidec 1/2 horsepower motor is designed as a direct replacement for carbonator pump applications. It operates at 1800 RPM with dual voltage capability, making it suitable for various industrial and HVAC systems requiring reliable pump motor performance.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1800
• Voltage: 120/240 V
• Amperage: 7.5/3.6 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 48YZ
• Rotation: Reversible
• Bearings: Sleeve Bearings

Product Features & Fitment

This motor features a special carbonator pump shaft and a base mount configuration for straightforward installation. It includes an auto overload protection system and a wiring diagram located on the motor nameplate to assist with proper electrical connections. The motor is designed for split-phase operation and utilizes Class B insulation for durability.

Warranty

1 Year Manufacturer Warranty
