6080 Nidec 1/2 hp 1800 RPM 115V ODP 1-Phase Carbonator Pump Motor Replacement

6080 Nidec 1/2 hp 1800 RPM 115V ODP 1-Phase Carbonator Pump Motor Replacement

This 6080 Nidec motor is a direct replacement for carbonator pump applications, designed to deliver reliable performance in beverage carbonation systems. It operates at 1/2 horsepower with a speed of 1800 RPM and is suitable for single-phase power supplies.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1800
• Voltage: 115 V
• Amperage: 8.4 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 48YZ
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a special carbonator pump shaft designed for precise fitment and optimal operation. It includes a face mount configuration and Class B insulation for durability. The motor is equipped with automatic overload protection and a wiring diagram is provided on the motor nameplate to assist with installation.

Warranty

1 Year Manufacturer Warranty
