8D20P3C Nidec 20 hp 1200 RPM 286T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor
8D20P3C Nidec 20 hp 1200 RPM 286T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor
8D20P3C Nidec 20 hp 1200 RPM 286T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor
8D20P3C Nidec 20 hp 1200 RPM 286T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor

Nidec

8D20P3C Nidec 20 hp 1200 RPM 286T Frame (Rigid Base) 460V TEFC 3-Phase Inverter Duty Electric Motor

(No reviews) Write a Review
$3,087.75
$2,756.44
SKU 8D20P3C
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 20 HP
RPM 1200
Phase Three Phase
Frame 286T
Enclosure TEFC
Hertz 60 Hz
Type Inverter Duty
Amperage 24.4 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 20 hp 1200 RPM, 24.4 amps 460 Volts 60 Hz Three Phase Motor
  • NEMA 286T Cast Iron Frame, Keyed Shaft 1 7/8" Diameter x 4 5/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 5 Year Manufacture Warranty, 3 year on inverter power

Corrosion resistant inverter duty motor is designed for use in petro-chemical and similar industries. Self-Certified Class 1, Division 2, Groups A, B, C, and D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. GA47

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 20 HP
RPM 1200
Phase Three Phase
Frame 286T
Enclosure TEFC
Hertz 60 Hz
Type Inverter Duty
Amperage 24.4 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
