Bison 011-348-4010 Gear Motor 1/4 hp 170 RPM 90VDC

Bison 011-348-4010 Gear Motor 1/4 hp 170 RPM 90VDC

The Bison 011-348-4010 is a 1/4 horsepower DC parallel shaft gear motor designed for industrial applications requiring reliable torque and reversible rotation. It serves as a suggested replacement for the Baldor GPP7452 and is compatible with Leeson speed controls 174307 and 174308.

Key Specifications

• Horsepower: 1/4 hp
• RPM: 170
• Voltage: 90 VDC
• Amperage: 2.51 amps
• Enclosure: TENV (Totally Enclosed Non-Ventilated)
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This 348 Series gear motor features a 2-stage gearhead with a precision-machined die-cast aluminum housing and hardened steel shafts and gearing, including a forged bronze worm gear. It is lubricated with a lifetime oil bath that is sealed and gasketed for maintenance-free operation. The motor includes a keyed shaft with a rear tapped hole to facilitate encoder mounting and supports any angle mounting. Optional accessories include the P198-300-0000 junction box. The motor utilizes replaceable brushes and has an insulation class B rating with a powder-coat gloss black finish.

Cross Reference

• Baldor GPP7452. Can use with Leeson speed control 174307, 174308

Warranty

• Bison Catalog Page
