Bison 011-348-5010 Gear Motor 1/8 hp 170 RPM 24VDC

SKU:
011-348-5010
Availability:
Bison is requiring minimum qty purchases, with a lead time of 12 weeks to manufacture the motors.
Weight:
16.00 LBS
Minimum Purchase:
25 units
Shipping:
Free Shipping
Confirmations:
All purchases understand the lead time requirements, we will not be sending out update emails.
Was: $906.59
Now: $725.27
Adding to cart… The item has been added
  • 348 Series DC Parallel Shaft Gear Motor - Subject to factory availability-email or call for availability
  • Torque 40 inch pounds
  • Over Hung lbs. = 240
  • 2 Stage
  • Rotation = Reversible
  • Rear tapped hole in shaft for encoder mount.
  • 1/8 hp 170 RPM, 5.18 amps, 24 Volts DC
  • TENV Enclosure, Keyed Shaft, Ball Bearings

Optional Accessories: P198-100-9121 Junction Box. Permanent Magnet motor, Insulation Class B; Finish: Powder-coat gloss black; Brushes: Replaceable; Rear tapped hole in shaft for encoder mount. Gearhead Specifications: Housing - Precision machined die cast aluminum; Shafts - Hardened steel; Gearing: Hardened Steel worm. Forged bronze gear; Lubrication: Lifetime oil bath, sealed and gasketed; Any angle mount; Bearings - Ball and Needle Bearings. Can use with Leeson speed control 175290.
