Bison Model 017-175-0013 Gear Motor 1/12 hp 122 RPM 230/460V 60/50HZ.

Part #
Bison Gear Motors
10.00 LBS
Calculated at checkout
$391.42 RRP:


  • 175 Series AC Parallel Shaft Gear Motor - Subject to factory availability-email or call for availability
  • Torque 38 inch pounds; Over Hung lbs. = 220
  • Rotation = Reversible; Junction Box Included
  • 1/12 hp 122 RPM, .60/.35 amps, 230/460V 50/60hz. Three Phase
  • TENV Enclosure, Keyed Shaft, Ball Bearings

Gearhead Specifications: Housing: Precision machined die cast aluminum. Lubrication: Lifetime oil bath, sealed and gasketed. Shafts: Hardened steel. Mounting: Face (any angle) or optional footplate. Gearing: 1st stage helical metal, balance spur metal. Bearings: Needle bearings on output shaft. P125-100-9998 Optional Bison Gearmotor Mounting Bracket. One Year Manufacture Warranty. Opening motor voids the warranty.

PDF Documents
