Bison 017-175-0096 Gear Motor 1/12 hp 17 RPM 230/460V 60/50HZ.

Bison 017-175-0096 Gear Motor 1/12 hp 17 RPM 230/460V 60/50HZ.

SKU:
017-175-0096
Availability:
Bison is requiring minimum qty purchases, with a lead time of 12 weeks to manufacture the motors.
Weight:
10.00 LBS
Minimum Purchase:
25 units
Shipping:
Free Shipping
Confirmations:
All purchases understand the lead time requirements, we will not be sending out update emails.
Was: $821.38
Now: $657.10
Adding to cart… The item has been added
  • 175 Series AC Parallel Shaft Gear Motor - Subject to factory availability-email or call for availability
  • Torque 150 inch pounds; Over Hung lbs. = 150
  • Rotation = Reversible; Junction Box Included
  • 1/12 hp 17 RPM .60/.35 amps, 230/460V 50/60hz. Three Phase
  • TENV Enclosure, Keyed Shaft, Ball Bearings

Gearhead Specifications: Housing: Precision machined die cast aluminum. Lubrication: Lifetime oil bath, sealed and gasketed. Shafts: Hardened steel. Mounting: Face (any angle) or optional footplate. Gearing: 1st stage helical metal, balance spur metal. Bearings: Needle bearings on output shaft. P125-100-9998 Optional Bison Gearmotor Mounting Bracket. One Year Manufacture Warranty. Opening motor voids the warranty.

!
