- 650 Series AC Parallel Shaft Gear Motor - Subject to factory availability-email or call for availability
- Torque 650 inch pounds; Over Hung lbs. = 900
- Rotation = Reversible; Junction Box Included
- 1/4 hp 7.9 RPM, .80 amps; 230V; 6-90 hz.; Three Phase
- TEFC Enclosure, Keyed Shaft, Ball Bearings
Motor: Meets NEMA MG 1 sct 31; Powder-coat gloss black; Motor Bearings: Double shielded ball; Thermostat: Signal type; closed. UL/CUL recognized. Gearhead Specifications: Precision machined die cast aluminum ; Lubrication: Lifetime oil bath; Hardened steel shafts; Mounting: Face (any angle) or footplate. Gearing: AGMA class 9 heat treated steel, 1st stage helical metal, balance spur metal. Bearings: Needle with thrust ball. One Year Manufacture Warranty. Opening motor voids the warranty.
