C683 Marathon 1/3 hp Basic Jet Pump Motor 1800/1500 RPM 115/208-230V ODP 56J Frame (no base)
C683 Marathon 1/3 hp Basic Jet Pump Motor 1800/1500 RPM 115/208-230V ODP 56J Frame (no base)
C683 Marathon 1/3 hp Basic Jet Pump Motor 1800/1500 RPM 115/208-230V ODP 56J Frame (no base)
C683 Marathon 1/3 hp Basic Jet Pump Motor 1800/1500 RPM 115/208-230V ODP 56J Frame (no base)
C683 Marathon 1/3 hp Basic Jet Pump Motor 1800/1500 RPM 115/208-230V ODP 56J Frame (no base)
C683 Marathon 1/3 hp Basic Jet Pump Motor 1800/1500 RPM 115/208-230V ODP 56J Frame (no base)
C683 Marathon 1/3 hp Basic Jet Pump Motor 1800/1500 RPM 115/208-230V ODP 56J Frame (no base)
C683 Marathon 1/3 hp Basic Jet Pump Motor 1800/1500 RPM 115/208-230V ODP 56J Frame (no base)

Marathon

C683 Marathon 1/3 hp Basic Jet Pump Motor 1800/1500 RPM 115/208-230V ODP 56J Frame (no base)

(No reviews) Write a Review
$200.00
$179.95
SKU MC683
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
STATUS DISCONTINUED
Voltage 115/208/230V
Horsepower 1/3 HP
RPM 1800
Frame 56J
Enclosure ODP
Hertz 60 Hz
Amperage 3.2 Amps
Bearings Ball Bearings
Service Factor 1.35
Insulation Class Class B
Rotation Clockwise
Adding to cart… The item has been added
Description



  • 1/3 hp 1800/1500 RPM, 6.4/3.0-3.2 amps, 115/208-230 volts, Capacitor Start / Induction Run
  • NEMA 56J Frame, 5'8" dia. by 1-5/8" long threaded stainless steel shaft, 60 Hz
  • Service Factor: 1.35, Overload protection: Auto
  • No base, CW rotation viewed opposite shaft end, Ball Bearings; Class B Insulation
  • 1 Year Manufacture Warranty

Spa pump motor. Not for pool use due to lack of suction cut-off. ODP = Open Drip Proof, 5KC36LN84X

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
STATUS DISCONTINUED
Voltage 115/208/230V
Horsepower 1/3 HP
RPM 1800
Frame 56J
Enclosure ODP
Hertz 60 Hz
Amperage 3.2 Amps
Bearings Ball Bearings
Service Factor 1.35
Insulation Class Class B
Rotation Clockwise
!
