CDP0754R TECO-Westinghouse 75 hp 1800 RPM 365T RB 230/460V TEFC 3-Phase Petro-Chem Crusher Motor

SKU:
CDP0754R
Weight:
1,075.00 LBS
Shipping:
Calculated at Checkout
$5,870.74
Adding to cart… The item has been added

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 75 hp 1800 RPM, 170/85.1 amps 230/460 Volts 60 Hz Three Phase
  • NEMA 365T Frame, 5 7/8 x 2 3/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP56)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

For use in Severe Duty Crushers, Chippers, or any High-Torque Application Potentially Having Explosive Gases. Certified for Class 1, Division 2, Groups B,C,D; and Class 2, Division 2, Groups F and G.
