Coleman-Mach 38204-069 Mach 15 RV Air Conditioner

38204-069 Coleman-Mach 15 Plus RV Air Conditioner

The Coleman-Mach 38204-069 is a premium, high-capacity roof-mounted RV air conditioner configured as a special multi-application model to deliver maximum cooling efficiency. Combining the powerhouse internal specifications of the benchmark -069 platform with a clean, high-visibility white composite exterior housing, it provides heavy-duty climate control for standard residential and commercial recreational vehicles, trailers, and mobile installations.

Key Specifications

• Capacity: 15,000 Nominal BTU
• Style: Medium Profile
• Type: Cooling Only (Non-Ducted)
• Ampere Rating: 14.8 Full-Load Amps
• Airflow Rate: Flows 320 CFM
• Refrigerant: Eco-Friendly, Low-GWP R-32
• Dimensions: 38.00 in. (L) x 26.10 in. (W) x 13.80 in. (H)
• Weight: 103.00 lbs.

Product Features & Fitment

This air conditioner features a streamlined medium-profile design that stands 13.8 inches above the roofline, optimizing aerodynamics to reduce highway wind drag while maximizing internal air chamber volume. Driven by an industry-leading 1/3 HP fan motor, it delivers an impressive 320 CFM of high-velocity airflow, making it exceptionally effective at pushing conditioned air through long, complex ducted ductwork as well as direct-discharge non-ducted ceiling plenums. Built for long-term road abuse, the closed-loop cooling system features all-copper tubing with gas-flux brazed joints alongside large evaporator and condenser coils with raised lance fins for rapid thermal dissipation in high-ambient desert temperatures.
