D2CP2PCR Nidec 2 hp 1800 RPM 56C (No Base) 115/230V ODP 1-Phase Motor
D2CP2PCR Nidec 2 hp 1800 RPM 56C (No Base) 115/230V ODP 1-Phase Motor
D2CP2PCR Nidec 2 hp 1800 RPM 56C (No Base) 115/230V ODP 1-Phase Motor
D2CP2PCR Nidec 2 hp 1800 RPM 56C (No Base) 115/230V ODP 1-Phase Motor

Nidec

D2CP2PCR Nidec 2 hp 1800 RPM 56C (No Base) 115/230V ODP 1-Phase Motor

(No reviews) Write a Review
$1,082.15
$965.77
SKU D2CP2PCR
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 2 HP
RPM 1800
Phase Single Phase
Enclosure ODP
Hertz 60 Hz
Amperage 17.0/8.5 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting C-Face
Adding to cart… The item has been added
Description
  • 2 hp 1800 RPM, 17.0/8.5 amps 115/230 Volts 60 Hz Cap Start Single Phase Motor
  • NEMA 56C Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class B Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C-Face motor for pumps, conveyors, air compressors, and blowers. Wiring diagram on motor name plate. ODP = Open Drip-Proof. T063CTB2237012B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/230V
Horsepower 2 HP
RPM 1800
Phase Single Phase
Enclosure ODP
Hertz 60 Hz
Amperage 17.0/8.5 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting C-Face
!
