D32V3B Nidec 1 1/2 hp 1200 RPM 182T (Rigid Base) 230/460V ODP Inverter-Duty 3-Phase Motor
D32V3B Nidec 1 1/2 hp 1200 RPM 182T (Rigid Base) 230/460V ODP Inverter-Duty 3-Phase Motor
D32V3B Nidec 1 1/2 hp 1200 RPM 182T (Rigid Base) 230/460V ODP Inverter-Duty 3-Phase Motor
D32V3B Nidec 1 1/2 hp 1200 RPM 182T (Rigid Base) 230/460V ODP Inverter-Duty 3-Phase Motor

Nidec

D32V3B Nidec 1 1/2 hp 1200 RPM 182T (Rigid Base) 230/460V ODP Inverter-Duty 3-Phase Motor

(No reviews) Write a Review
$663.55
$592.37
SKU D32V3B
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 1/2 HP
RPM 1200
Phase Three Phase
Enclosure ODP
Hertz 60 Hz
Amperage 5.2/2.6 Amps
Bearings Ball Bearings
Speeds 1-Speed
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1 1/2 hp 1200 RPM, 5.2/2.6 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 182T Rolled Steel Frame with Cast Aluminum End Bells, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Speed controllable motor for material handling, pumps, and fans, in normal environments. 5:1 speed range at constant torque, 20:1 at variable torque. NEMA design B. Brake provisions. Wiring diagram on motor name plate. ODP = Open Drip-Proof. FV31

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 1/2 HP
RPM 1200
Phase Three Phase
Enclosure ODP
Hertz 60 Hz
Amperage 5.2/2.6 Amps
Bearings Ball Bearings
Speeds 1-Speed
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
