D3P3G Nidec 3 hp 1200 RPM 213T Frame (Rigid Base) 575V ODP 3-Phase Electric Motor
D3P3G Nidec 3 hp 1200 RPM 213T Frame (Rigid Base) 575V ODP 3-Phase Electric Motor
D3P3G Nidec 3 hp 1200 RPM 213T Frame (Rigid Base) 575V ODP 3-Phase Electric Motor
D3P3G Nidec 3 hp 1200 RPM 213T Frame (Rigid Base) 575V ODP 3-Phase Electric Motor

Nidec

D3P3G Nidec 3 hp 1200 RPM 213T Frame (Rigid Base) 575V ODP 3-Phase Electric Motor

(No reviews) Write a Review
$801.55
$715.30
SKU D3P3G
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 3 HP
RPM 1200
Phase Three Phase
Frame 213T
Enclosure ODP
Hertz 60 Hz
Amperage 3.6 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 3 hp 1200 RPM, 3.6 amps 575 Volts 60 Hz Three Phase Motor
  • NEMA 213T Rolled Steel Frame, Keyed Shaft 1 3/8" Diameter x 3 3/8"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor designed for use with pumps, fans, and compressors where contaminants are minimal. Wiring diagram on motor name plate. ODP = Open Drip Proof. DZ93

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 3 HP
RPM 1200
Phase Three Phase
Frame 213T
Enclosure ODP
Hertz 60 Hz
Amperage 3.6 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
