D3PA2D Nidec 3 hp 1800 RPM 182T Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor

D3PA2D Nidec 3 hp 1800 RPM 182T Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor

This general-purpose electric motor is designed for reliable operation in pumps, fans, and compressors where minimal contaminants are present. It serves as a direct replacement for similar 3 hp, 1800 RPM, three-phase motors with a NEMA 182T frame.

Key Specifications

• Horsepower: 3 hp
• RPM: 1800
• Voltage: 208-230/460 V
• Amperage: 8.3-7.6/3.8 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 182T Rolled Steel Frame
• Shaft Dimensions: 1 1/8" Diameter x 2 3/4" Length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The motor features a rigid base mount suitable for secure installation and includes a keyed shaft for reliable coupling. It is built with Class F insulation for enhanced thermal protection and comes with a wiring diagram located on the motor nameplate to assist with proper electrical connections. This motor does not include overload protection.

Warranty

1 Year Manufacturer Warranty
