D7P3H Nidec 7 1/2 hp 1200 RPM 254T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor

SKU:
D7P3H
Weight:
150.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $1,121.00
Now: $1,000.70
Adding to cart… The item has been added
  • 7 1/2 hp 1200 RPM, 21.9 amps 200 Volts 60 Hz Three Phase Motor
  • NEMA 254T Rolled Steel Frame, Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor designed for use with pumps, fans, and compressors where contaminants are minimal. Wiring diagram on motor name plate. ODP = Open Drip Proof. HE70
