Dayton Model 52JE48 DC Gear Motor 3.4 RPM 1/425 hp 12VDC

Dayton Model 52JE48 DC Gear Motor 3.4 RPM 1/425 hp 12VDC

The Dayton Model 52JE48 is a durable DC gear motor designed for low-speed, high-torque applications. It replaces Dayton model 2L005 and is ideal for continuous duty operations requiring reversible rotation.

Key Specifications

• Horsepower: 1/425 hp
• RPM: 3.4
• Voltage: 12 VDC
• Amperage: 0.5 amps
• Shaft Dimensions: 5/16" diameter x 1" length with flat
• Rotation: Reversible
• Bearings: Sleeve bearings

Product Features & Fitment

This motor features a 44 inch-pound torque rating and supports an overhung load of up to 30 pounds. It is designed for all-position mounting and continuous duty operation. Note that the motor does not include thermal protection.

Cross Reference

• Dayton 2L005

Warranty

1 Year Manufacturer Warranty
