DHP0202G TECO-Westinghouse 20 HP 3600 RPM 254T 230/460V ODP Cast Iron SGR 3-Phase Motor

SKU:
DHP0202G
Weight:
233.00 LBS
Shipping:
Calculated at Checkout
$1,216.62
Adding to cart… The item has been added

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 20 hp 3600 RPM, 45.5/22.8 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 254T Frame, 4 x 1 5/8" Dia. Keyed Shaft
  • Cast Iron Frame, Open Drip Proof
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

General purpose SGR motor for use on pumps, fans, and compressors. The SGR bearing protection ring resists bearing damage by diverting stray electric currents to ground.
