DJ34P3DM US Motors 3/4 hp 1200 RPM 3-phase 143JM Frame 208-230/460V (ODP) Close-Coupled Pump Motor
DJ34P3DM US Motors 3/4 hp 1200 RPM 3-phase 143JM Frame 208-230/460V (ODP) Close-Coupled Pump Motor
DJ34P3DM US Motors 3/4 hp 1200 RPM 3-phase 143JM Frame 208-230/460V (ODP) Close-Coupled Pump Motor
DJ34P3DM US Motors 3/4 hp 1200 RPM 3-phase 143JM Frame 208-230/460V (ODP) Close-Coupled Pump Motor

US Motors

DJ34P3DM US Motors 3/4 hp 1200 RPM 3-phase 143JM Frame 208-230/460V (ODP) Close-Coupled Pump Motor

(No reviews) Write a Review
$614.10
$547.98
SKU DJ34P3DM
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/california.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3/4 HP
RPM 1200
Phase Three Phase
Frame 143JM
Enclosure ODP
Hertz 60 Hz
Amperage 2.8/1.4 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 3/4 HP 1200 RPM, 2.8-2.8/1.4 amps, 208-230/460V 60hz. 3 Phase.
  • NEMA 143JM Rolled Steel Frame with cast aluminum end-shields, JM stainless steel shaft
  • 1.15 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Open Drip Proof (ODP)
  • Rigid Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. ODP = Open Drop Proof, Proof, FF63

Specifications
Compliance Tab /content/product_tabs/california.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3/4 HP
RPM 1200
Phase Three Phase
Frame 143JM
Enclosure ODP
Hertz 60 Hz
Amperage 2.8/1.4 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
!
