DJPP7/54 TECO Westinghouse 7 1/2 hp 1800 RPM 213/215JP Frame 230/460V ODP Close-Coupled 3-Phase Motor
DJPP7/54 TECO Westinghouse 7 1/2 hp 1800 RPM 213/215JP Frame 230/460V ODP Close-Coupled 3-Phase Motor
DJPP7/54 TECO Westinghouse 7 1/2 hp 1800 RPM 213/215JP Frame 230/460V ODP Close-Coupled 3-Phase Motor
DJPP7/54 TECO Westinghouse 7 1/2 hp 1800 RPM 213/215JP Frame 230/460V ODP Close-Coupled 3-Phase Motor

TECO WESTINGHOUSE

DJPP7/54 TECO Westinghouse 7 1/2 hp 1800 RPM 213/215JP Frame 230/460V ODP Close-Coupled 3-Phase Motor

(No reviews) Write a Review
$730.37
SKU DJPP7/54
Shipping Calculated at Checkout
Voltage 230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 215JP
Enclosure ODP
Hertz 60 Hz
Amperage 9.55 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 7 1/2 hp 1800 RPM, 19.1/9.55 amps 230/460 Volts 60hz. Three Phase
  • NEMA 213/215JP Frame, Special Shaft
  • Rolled Steel Frame, Enclosure: Open Drip Proof (IP22)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Applications: Fans & Blowers, Pumps, Crushers, Compressors, Mixers, Conveyors

Specifications
Voltage 230/460V
Horsepower 1/2 HP
RPM 1800
Phase Three Phase
Frame 215JP
Enclosure ODP
Hertz 60 Hz
Amperage 9.55 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
