DTP0304 TECO Westinghouse 30 hp 1800 RPM 284/286T Frame 230/460V ODP 3-Phase Motor
DTP0304 TECO Westinghouse 30 hp 1800 RPM 284/286T Frame 230/460V ODP 3-Phase Motor
DTP0304 TECO Westinghouse 30 hp 1800 RPM 284/286T Frame 230/460V ODP 3-Phase Motor
DTP0304 TECO Westinghouse 30 hp 1800 RPM 284/286T Frame 230/460V ODP 3-Phase Motor

TECO WESTINGHOUSE

DTP0304 TECO Westinghouse 30 hp 1800 RPM 284/286T Frame 230/460V ODP 3-Phase Motor

(No reviews) Write a Review
$1,866.11
$1,599.95
SKU DTP0304
Shipping Calculated at Checkout
Voltage 230/460V
Horsepower 30 HP
RPM 1800
Phase Three Phase
Frame 286T
Enclosure ODP
Hertz 60 Hz
Amperage 69.4/34.7 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR



  • 30 hp 1800 RPM, 69.4/34.7 amps 230/460 Volts 60hz. Three Phase
  • NEMA 284/286T Frame, Keyed Shaft 1 7/8" Diameter x 4 5/8"
  • Rolled Steel Frame, Enclosure: Open Drip Proof (IP22)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Applications: Fans & Blowers, Pumps, Crushers, Compressors, Mixers, Conveyors

Specifications
Voltage 230/460V
Horsepower 30 HP
RPM 1800
Phase Three Phase
Frame 286T
Enclosure ODP
Hertz 60 Hz
Amperage 69.4/34.7 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
