EE612 Nidec 2 hp 3600 RPM 56C Frame (No Base) 208-230/460V ODP 3-Phase Electric Motor
EE612 Nidec 2 hp 3600 RPM 56C Frame (No Base) 208-230/460V ODP 3-Phase Electric Motor
EE612 Nidec 2 hp 3600 RPM 56C Frame (No Base) 208-230/460V ODP 3-Phase Electric Motor
EE612 Nidec 2 hp 3600 RPM 56C Frame (No Base) 208-230/460V ODP 3-Phase Electric Motor

Nidec

EE612 Nidec 2 hp 3600 RPM 56C Frame (No Base) 208-230/460V ODP 3-Phase Electric Motor

(No reviews) Write a Review
$787.75
$702.88
SKU EE612
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 2 HP
RPM 3600
Phase Three Phase
Frame 56C
Enclosure ODP
Hertz 50/60 Hz
Amperage 5.1/2.5 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
Adding to cart… The item has been added
Description
  • 2 hp 3600 RPM, 5.5-5.1/2.5 amps 208-230/460 Volts 50/60 Hz Three Phase Motor
  • NEMA 56C frame Keyed Shaft 5/8" Diameter x 1 7/8" Long
  • Service Factor: 1.15, Overload protection = None
  • Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C-Face motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. ODP = Open Drip Proof. P063FGZ4131015J

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 2 HP
RPM 3600
Phase Three Phase
Frame 56C
Enclosure ODP
Hertz 50/60 Hz
Amperage 5.1/2.5 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
!
