EE734-5 Nidec 3 HP 3600 RPM 3-Phase 575V 56J Frame (Base) ODP Special Pump Motor
EE734-5 Nidec 3 HP 3600 RPM 3-Phase 575V 56J Frame (Base) ODP Special Pump Motor
EE734-5 Nidec 3 HP 3600 RPM 3-Phase 575V 56J Frame (Base) ODP Special Pump Motor
EE734-5 Nidec 3 HP 3600 RPM 3-Phase 575V 56J Frame (Base) ODP Special Pump Motor

Nidec

EE734-5 Nidec 3 HP 3600 RPM 3-Phase 575V 56J Frame (Base) ODP Special Pump Motor

(No reviews) Write a Review
$882.05
$787.64
SKU EE734-5
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 3 HP
RPM 3600
Phase Three Phase
Frame 56J
Enclosure ODP
Hertz 60 Hz
Amperage 3.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
Adding to cart… The item has been added
Description

    3 hp 3600 RPM, 3.0 amps 575 Volts 60 Hz Three Phase Motor
    NEMA 56J Frame, Shaft 5/8" Diameter x 1 7/8" Long with threaded end
    Service Factor: 1.15, Overload protection = None
    Rigid Base Mount, Ball Bearings, Class B Insulation, CCW  Drive End
    1 Year Manufacture Warranty

Special purpose three phase C- Face motor is usually used in commercial applications involving specialized pumps.  Wiring diagram on motor name plate. ODP = Open Drip-Proof. BK78

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 3 HP
RPM 3600
Phase Three Phase
Frame 56J
Enclosure ODP
Hertz 60 Hz
Amperage 3.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
!
