EEQ750 US Motors 7 1/2 hp 3450 RPM 1-phase 213JMZ Frame 230V Close-Coupled Pool Pump Motor (Pentair EQ 357066 Replacement)

EEQ750 US Motors 7 1/2 hp 3450 RPM 1-phase 213JMZ Frame 230V Close-Coupled Pool Pump Motor (Pentair EQ 357066 Replacement)

This EEQ750 motor is a direct replacement for the Pentair EQ 357066 pool pump motor, designed for commercial pool pump applications. It delivers reliable performance with a 7.5 horsepower rating and is engineered for use with Pentair EQ750 pump models.

Key Specifications

• Horsepower: 7 1/2 HP
• RPM: 3450
• Voltage: 230V, 60 Hz
• Amperage: 30.4 amps
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 213JMZ
• Shaft Dimensions: Special dimension stainless steel shaft
• Rotation: Non-Reversible, CCW facing the shaft
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid JMZ base and black paint finish, with a capacitor start single-phase design and Class F insulation. It includes an auto overload thermal protection system and a 1.15 service factor for enhanced durability. Installation requires a compatible shaft seal, such as PS-360 or VG-360, to ensure proper pump sealing and operation.

Cross Reference

• Pentair Motor No. 357066
• Fits Pentair Pump Model No. EQ750

Warranty

1 Year Manufacturer Warranty
