EP0504C TECO Westinghouse 50 hp 1800 RPM 326TC Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor
EP0504C TECO Westinghouse 50 hp 1800 RPM 326TC Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor
EP0504C TECO Westinghouse 50 hp 1800 RPM 326TC Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor
EP0504C TECO Westinghouse 50 hp 1800 RPM 326TC Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor

TECO WESTINGHOUSE

EP0504C TECO Westinghouse 50 hp 1800 RPM 326TC Cast Iron 230/460V TEFC Severe Duty 3-Phase Motor

(No reviews) Write a Review
$4,062.52
SKU EP0504C
Shipping Calculated at Checkout
Voltage 230/460V
Horsepower 50 HP
RPM 1800
Phase Three Phase
Frame 326TC
Enclosure TEFC
Hertz 60 Hz
Amperage 56.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Severe Duty
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 50 hp 1800 RPM, 113/56.9 amps 230/460 Volts 60Hz. Three Phase
  • NEMA 326TC Frame, 5 1/4 x 2 1/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP54)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

Applications: Crushers, Compressors, Mixers, Conveyors, Any Severe Duty Application

Specifications
Voltage 230/460V
Horsepower 50 HP
RPM 1800
Phase Three Phase
Frame 326TC
Enclosure TEFC
Hertz 60 Hz
Amperage 56.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Severe Duty
!
