EPV0034C TECO-Westinghouse 3 hp 1800 RPM 182TC Vertical 230/460V TEFC Severe Duty Petro-Chem 3-Ph Motor

EPV0034C TECO-Westinghouse 3 hp 1800 RPM 182TC Vertical 230/460V TEFC Severe Duty Petro-Chem 3-Ph Motor

This TECO-Westinghouse NEMA Premium electric motor is designed for severe duty petro-chemical applications involving explosive gases. It replaces standard motors in hazardous environments and offers reliable performance with inverter compatibility and robust construction.

Key Specifications

• Horsepower: 3 hp
• RPM: 1800
• Voltage: 230/460 V
• Amperage: 7.70/3.85 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC), IP54
• Frame / Diameter: NEMA 182TC Frame, 2 5/8 x 1 1/8" Diameter
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

The motor features a cast iron frame with a rigid base for secure mounting and durability in harsh environments. It is suitable for inverter duty with a speed range of 20:1 for variable torque and 10:1 for constant torque, meeting NEMA MG-1 Part 31.4.4.2 standards. This motor is UL Recognized, CSA Approved, and CE Marked, certified for Class 1, Division 2, Groups B, C, D hazardous locations.

Warranty

1 Year Manufacturer Warranty
